Key Specifications
| T41.140SLP Telehandler | |
| Horsepower | 100 hp |
| Rated Operating Capacity (ISO) | 4100 kg |
| Operating Weight | 9960 kg |
Performance
| T41.140SLP Telehandler | |
| Maximum Lift Height (on 24″ tire, stabilizers) | 13650 mm |
| Maximum Lift Capacity | 4100 kg |
| Max Forward Reach (24″ tires) | 9730 mm |
| Breakout Force | 12300 kg |
| Auxiliary Standard Flow | 65 L/min |
| Operating Weight | 9960 kg |
Engine
| T41.140SLP Telehandler | |
| Engine Model | PERKINS / 1104D-44TA |
| Emission | Stage IIIA |
| Horsepower | 100 hp |
| Fuel Tank | 145 liter |
| Standard Tires | 400/80-24″ |
| Max Travel Speed – Standard Tire | 30 km/h |
| Max Travel Speed – Optional | – |
| Steering Modes | 3 steering modes with semi-automatic wheel alignment: 2 wheels / 4 wheels / crab |
Configuration
| T41.140SLP Telehandler | |
| Compact Stabilizers | O |
| Frame Leveling | O |
| Boom Positioning System (Built-in Side-Shift System) | O |
| Frame Tilt Angle | ± 4 deg |
Dimension
| T41.140SLP Telehandler | |
| Overall Length to Forks Face | 6108 mm |
| Overall Length to Front Tires | 4950 mm |
| Length from Front Axle to Forks Face | 2151 mm |
| Wheelbase | 2850 mm |
| Length from Rear Axle to Machine Rear | 1107 mm |
| Overall Height (Std Cab) | 2520 mm |
| Ground Clearance | 509 mm |
| Width over Standard Tires | 2418 mm |
| Overall Width with Stabilizers Fully Deployed | 2619 mm |
| Track Width (Front & Rear) | 1992 mm |
| External Turning Radius at Tires | 4150 mm |
| Outside Width of Cab | 930 mm |
| BPS Lateral Amplitude | ± 525 deg |
